Description
The 100 Series Submersible Level Sensor provides continuous level measurement for both corrosive and non-corrosive liquids. These submersible tank level sensors have been designed for the toughest industrial applications. Unlike ultrasonic level transmitters, our liquid level sensors are completely unaffected by any foam, vapor, turbulence or condensate in the tank.
The Pressure Sensor works by sitting at the bottom of the tank and measuring the head pressure of the liquid pushing down on its ceramic sensing diaphragm. The only submersible level sensor with an integral molded weight to ensure the sensor will remain at the bottom and you will always receive an accurate, reliable reading.
These plastic level sensors have been engineered to be completely corrosion resistant. They are available in PVC, PP, PVDF and PTFE Teflon® making them the perfect liquid level measurement devices. All models come equipped with a Teflon® jacketed cable and a Kalrez® O-ring seal to ensure it stands up to the industry’s most corrosive chemicals.
Our Continuous Level Transmitters require no programming, have no moving parts and are engineered with a non-clogging design. They are the industry’s simplest, most reliable level sensors, making them the perfect solution for tough applications where ultrasonics will not preform.
Features:
- Excellent Chemical Resistance
- Integrally Molded Weight-No Floating
- Kalrez® O-Rings | PTFE Teflon® Coated Cable
- Standard 0-34ft Range ( Others Available)
- +/- 0.5% Accuracy
- 4-20mA Output
- Industrial Heavy Duty Design
Applications:
- Suitable for: Foam, Vapor, Turbulence, Condensate
- Liquid Chemical Storage
- Chemical Sumps
- Tank Level Measurement
- Tank Monitoring System
- Continuous Level Measurement
Sold as sensor only - see IVX Pressure Sensor for use with IVX-BETA Tank Level Tracking & Reporting System
